About Measurement Times and Measurement Speed
When the contact check is enabled, the contact check time will be added to the analog measure-
ment times listed on the previous page.
Contact check
Contact check timing Contact check time
BEFORE 5.5 ms
AFTER 5.5 ms
BOTH 10 ms
• When using the external trigger setting, 500 µs is added to the "Analog measurement signal (INDEX)"
(p. 217) when the conditions outlined in the following table apply:
External trigger
Range Low Z high
accuracy mode
Measure-
ment level
Measurement
frequency
DC bias Added
time
100 m
Ω
, 1
Ω
OFF All level DC, all frequency OFF 500 µs
100 m
Ω
, 1
Ω
ON 0.01 to 1 V DC, all frequency OFF 500 µs
10
Ω
OFF 0.01 to 1 V DC, 4 Hz to 1 MHz OFF 500 µs
Measurement times (E
________
OM)
Measurement times= I
____________
NDEX+A+B+C+D+E
A: Calculation time (no OPEN/SHORT/LOAD correction, HOLD range, no screen display, nor-
mal measurement
*
)
Measurement speed Calculation time
FAST
All frequencies 0.5 ms
MED
SLOW
SLOW2
*: Times are given for measurement while not using the comparator function or BIN function.
B: OPEN/SHORT/LOAD correction time
OPEN/SHORT/LOAD correction Correction time
Disabled 0.0 ms
Enabled MAX 0.4 ms
C: Judgment time
Judgment mode Judgment time
Disabled (normal measurement
*
) 0.0 ms
Comparator measurement MAX 0.4 ms
BIN measurement MAX 0.8 ms
*: Times are given for measurement while not using the comparator function or BIN function.
