Loading Instrument Settings
8.6 Loading Instrument Settings
Loading settings les or panel les
This section describes how to load a setting le (SET) or panel le (PNL) that is saved to the USB
ash drive, and to restore the settings.
Screen display method (For more information, see p. 29.):
(Measurement screen) FILE key>(FILE screen) LIST tab
1
Insert the USB ash drive into the front
USB connector (p. 138).
2
Select the SETTING folder with the
keys and touch the SELECT key.
1
2
3
Select the setting le (SET) or panel le
(PNL) to load with the keys and
touch the LOAD key.
1
2
Touch when you wish to check the contents of
a le.
(See p. 157)
4
Touch the LOAD key.
Touch when you wish to cancel the load op-
eration.
(The dialog box will be closed.)
The le will be loaded and applied as the
current settings.
5
Touch the EXIT key.
Displays the measurement screen.
If a load error is displayed
If an error is displayed, the following
causes may be to blame:
• The setting le is damaged.
• The le is not a setting le that can be
read by the instrument.
Touch the CANCEL key.
The load operation will be canceled, and
the dialog box will be closed.
8
Using USB Flash Drive (Saving and Loading Data)
