Enlarging Display of Measurement Values
3.3 Enlarging Display of Measurement Values
The measurement values and comparator judgment results can be displayed in enlarged form.
This functionality provides a convenient way to make measured values easier to view.
Touch the ZOOM ON key.
Magnication Display Screen
Normal measurement
To cancel the zoom display:
Touch the ZOOM OFF key.
Comparator measurement BIN measurement
• Indicates the position of the measurement value relative
to the comparator thresholds with a bar.
• The bars will not be displayed unless both upper and
lower limit values have been set.
If the instrument is turned off while using the zoom display, the zoom display will
remain activated when the instrument is next turned on.
