Hioki IM3536 - Displaying the USB Flash Drive Information

160
Displaying the USB Flash Drive Information
8.10 Displaying the USB Flash Drive Information
Allows you to check the usage rate and le system of the USB ash drive.
Screen display method (For more information, see p. 29.):
(Measurement screen) FILE key>(FILE screen) LIST tab
1
Insert the USB ash drive into the front
USB connector (p. 138).
2
Touch the part indicating the disc infor-
mation.
File system : File system type
All : Total size
Used : Space used
Avail : Space free
3
Touch the EXIT key.
The dialog box will be closed.
4
Touch the EXIT key.
Displays the measurement screen.
