Saving Settings Data
8.5 Saving Settings Data
Saving instrument settings other than panels
This section describes how to save instrument settings other than panels on a USB ash drive. The
extension of the setting le is “.SET.” This function is convenient for when you want to back up the
setting state of the instrument.
For the settings that are saved, refer to "Appx. 11 Initial Settings Table" (p. Appx.15).
Screen display method (For more information, see p. 29.):
(Measurement screen) FILE key>(FILE screen) LIST tab
1
Insert the USB ash drive into the front
USB connector (p. 138).
2
Touch the SAVE key.
3
Touch the SAVE key.
Touch when you wish to cancel the
save operation.(The dialog box will
be closed.)
Touch when you wish to change the lename of
the setting le.
(A lename entry dialog box will be displayed.)
The measurement data is saved.
4
Touch the EXIT key.
Displays the measurement screen.
• Touching the SAVE key will cause a SETTING folder to be automatically created on the USB ash drive,
and setting les will be saved there.
• Filenames are automatically assigned based on the time and date by default, but they can be changed by
touching the RENAME key.
(Example:Saved at 16:31:44 on September 30, 2014→140930163144.SET)
• If a setting le with the same name already exists, a dialog box conrming whether you wish to overwrite
the le will be displayed.
8
Using USB Flash Drive (Saving and Loading Data)
