Hioki IM3536 - 8 Using USB Flash Drive (Saving and Loading Data)

137
8
Using USB Flash Drive (Saving
and Loading Data)
Before using this functionality, be sure to read "Before Using the USB Flash Drive" (p. 14).
This section describes how to save measurement data, instrument settings, and other data on a
USB ash drive as well as how to load data that has been saved on a USB ash drive.
Checking the Contents of
Files
Allows you to check the contents of les saved on a USB ash drive.
Saving data
Allows you to save data from the instrument to a USB ash drive.
• Measurement results (p. 141)
• Screen copy (p. 150)
• Panel (measurement conditions and correction values), and instru-
ment settings (p. 153)
Loading settings data
Allows you to load settings data from a USB ash drive into the instru-
ment.
• Panel (measurement conditions and correction values), and instru-
ment settings (p. 155)
Other
• Allows you to format (initialize) a USB ash drive (p. 140).
• Allows you to check the contents of les on a USB ash drive (p. 157).
• Allows you to delete les and folders from a USB ash drive (p. 158)
• This section describes how to create a folder on a USB ash drive
(p. 159).
• Allows you to check the usage rate and le system of the USB ash
drive (p. 160).
File format
The following les can be handled by the instrument.
Content Format Extension
Screen display
(TYPE)
- Folder - FDR
Measurement data CSV le .csv CSV
Screen copy data BMP le .bmp BMP
Instrument settings data Setting le .SET SET
Panel (measurement conditions and correction values) Panel le .PNL PNL
The instrument cannot display double-byte characters (Japanese, etc.). A double-byte characters is
replaced by "??."
Supported USB ash drive specications
Connector USB type A
Electrical specication USB2.0
Power supply 500 mA maximum
No. of ports 1
Compatible USB device USB Mass Storage Class
