Accessories and Options
10.3 Accessories and Options
Accessories: Refer to "Accessories" (p. 1).
Options: Refer to "Options (reference: open and short correction states)" (p. 2).
10.4 Function specications
DC measurement (DC resistance measurement)
DC adjustment
Function Functionality for measuring and canceling the circuit offset
ON/OFF selectable
When ON : Acquires the offset value at each measurement.
When OFF: Uses the offset value acquired initially in subsequent measurements.
Offset value acquisition
methods
(When set to “off”)
• Change the Rdc range (the offset is acquired automatically when the range
is changed).
• Change the Rdc low Z high accuracy mode setting (ON/OFF) while using a
range from 100 m
Ω
to 10
Ω
(value acquisition will be performed automati-
cally when the setting is changed).
• Change the adjust delay time (value acquisition will be performed auto-
matically when the delay time is changed).
• Touch the GET DCR OFFSET key on the screen.
• I
nput a signal from an external device to the instrument’s EXT I/O connector.
• Send a communications command from an external device to the instru-
ment’s interface.
Default setting ON
DC delay
Function Sets the time until DC resistance measurement starts.
Setting range 0.0000 s to 9.9999 s (0.0001 s resolution)
Default setting 0.0000 s
Adjustment delay
Function Sets the time to wait before starting offset measurement so that a stable
measured value can be obtained.
Setting range 0.0030 s to 9.9999 s (0.0001 s resolution)
Default setting 0.0030 s
Power supply frequency setting
Function Sets the frequency of the power supply being used.
Setting value 50 Hz/ 60 Hz
Default setting 60 Hz
Average
Function Performs processing to average measured values.
Setting range 1 to 256 (1 step)
Averaging method Arithmetic average
Default setting 1 (Average OFF)
10
Specications
