Function specications
Trigger
Function Uses a specic signal to time the start of measurement.
Trigger types Internal trigger: Automatically generates a trigger signal internally to repeat
measurement.
External trigger: Allows you to control the instrument’s measurement opera-
tion by inputting a trigger signal from an external device.
Trigger source: Manual, communication command, EXT I/O
Default setting Internal trigger
Average
Function The measured values can be averaged.
Setting range 1 to 256 (1 step)
Average method Internal trigger: Moving average from the current value to the set number of
averaging iterations in the past
External trigger: Arithmetic average of the set number of averaging iterations
from trigger input
Default setting 1 (Average OFF)
Trigger delay
Function Sets the delay time from trigger input to measurement.
Setting range 0.0000 s to 9.9999 s (0.0001 s resolution)
Default setting 0.0000 s
Trigger synchronous output
Function Outputs the measurement signal after trigger input and applies it to the
sample during measurement only.
Allows you to set a wait time until data is acquired.
Operation mode OFF/ON
Setting range 0.0010 s to 9.9999 s (0.0001 s resolution)
Default setting OFF (setting: 0.0010 s)
AUTO range limit
Function Allows you to limit the auto range selection (by setting lower limit and upper
limit ranges).
Default setting Lower limit range: 100 m
Ω
, Upper limit range: 100 M
Ω
Range synchronization function
Function • Allows you to set measurement conditions for each measurement range.
• The following measurement conditions can be set:
AC measurement: Speed, Average, Trigger delay, and trigger synchronization
DC measurement: Speed, and Average
Operation mode OFF/ON
Default setting OFF
