Function specications
BIN measurement
Function • Displays up to 10 judgment results for two parameters (the No. 1 param-
eter and No. 3 parameter) (BIN1 to BIN10, OUT OF BINS).
• Allows you to output judgment results to an external device from EXT I/O.
Judgment method • Set as absolute values:
Set the upper and lower limits for the measurement parameters as abso-
lute values.
• Set as percentage:
Enter the reference value and set the upper and lower limits as percentag-
es of the reference value. (Measured values for the measurement param-
eters will be displayed as they are.)
• Set as deviation percentage:
Enter the reference value and set the upper and lower limits as percent-
ages of the reference value. (Measured values will be displayed in terms
of their deviation from the reference value.)
Valid setting range • Set as absolute values : -9.99999 G to 9.99999 G
• Set as percentage : -999.999% to 999.999%
• Set as deviation percentage : -999.999% to 999.999%
Default setting OFF
Comparator
Function • Displays measurement results for two parameters (the No. 1 parameter
and the No. 3 parameter) as a HI/IN/LO result.
• Allows you to output judgment results to an external device from EXT I/O.
Judgment method • Set as absolute values:
Set the upper and lower limits for the measurement parameters as abso-
lute values.
• Set as percentage:
Enter the reference value and set the upper and lower limits as percentag-
es of the reference value. (Measured values for the measurement param-
eters will be displayed as they are.)
• Set as deviation percentage:
Enter the reference value and set the upper and lower limits as percent-
ages of the reference value. (Measured values will be displayed in terms
of their deviation from the reference value.)
Valid setting range • Set as absolute values : -9.99999 G to 9.99999 G
• Set as percentage : -999.999% to 999.999%
• Set as deviation percentage : -999.999% to 999.999%
Default setting OFF
Conductivity and permittivity calculations
Function Measures conductivity and permittivity after the user sets conditions used in
calculating conductivity and permittivity.
Settings • L: Sample length (mm)
• A: Sample cross-sectional area (mm
2
)
• C: Selection of whether to use Cs (equivalent series capacitance) or Cp
(equivalent parallel capacitance) in calculations (default setting: Cs)
Valid setting range • L: 0.000001 mm to 1000000 mm (default setting: 20.00000 mm)
• A: 0.000001 mm
2
to 1000000 mm
2
(default setting: 12.00000 mm
2
)
Equation
Conductivity
σ
=
L
Z×A
(
Z
: Impedance value), permittivity
ε
=
L
A
×C
10
Specications
