Loading Instrument Settings
Loading settings les including panel les (ALL LOAD function)
This section describes how to load settings les (ALL) including panel les saved on the USB ash
drive with the ALL SAVE function and restore the stored settings.
Screen display method (For more information, see p. 29.):
(Measurement screen) FILE key>(FILE screen) LIST tab
1
Insert the USB ash drive into the front
USB connector (p. 138).
2
Select the SETTING folder with the 
keys and touch the SELECT key.
1
2
3
Using the  keys, select the folder
which settings were saved with the all
save function and touch the SELECT
key.
1
2
4
Using the  keys, select the le
which TYPE is ALL and touch the ALL
LOAD key.
1
2
5
Touch the LOAD key.
When you want to cancel loading, touch this
key.
(The dialog box will be closed.)
All les saved in the folder will be loaded
and applied as the current settings.
6
Touch the EXIT key.
Displays the measurement screen.
• When the load operation is performed, all current instrument settings will be deleted.
• If the instrument is unable to load the settings le, a beep will sound.
• Refer to "If a load error is displayed" (p. 155).
