179
Internal Circuitry
Output Circuit connection examples
ISO_COM
Output
Negative-logic
output
Iutput
Common
Connection to relay Connection to LED
Negative-logic output
ISO_COM
Output
Output
Wired or
30 V max
50 mA max
IM3536
IM3536
Iutput
Common
PLC PLC
Connection to programmable controller
(plus common input)
Connection to programmable controller
(negative common input)
ISO_COM
Output
30 V max
IM3536
ISO_COM
Output
30 V max
IM3536
ISO_COM
ISO_COM
Output
Output
IM3536IM3536
9
External Control
