66
Setting Measurement Conditions (basic settings)
When the trigger synchronization function is off
Data acquisition
AC measurement
(trigger synchronization off)
DC
delay
Adjustment
delay
Data
acquisition
Data
acquisition
DC measurement
(trigger synchronization off)
(DC adjustment on)
DC measurement
(trigger synchronization off)
(DC adjustment off)
Data
acquisition
Data acquisition
Switching time
3.5 ms
DC
delay
Data
acquisition
Adjustment
delay
Data
acquisition
DC measurement
after AC measurement
(trigger synchronization off)
(DC adjustment on)
Trigger
delay
Trigger delay
Trigger delay
Trigger delay
Data acquisition
Switching time
3.5 ms
DC
delay
Data
acquisition
DC measurement
after AC measurement
(trigger synchronization off)
(DC adjustment off)
Trigger
delay
Trigger delay : Time from trigger to start of measurement
0.0 ms to 9.9999 s
Trigger
synchronization delay：Time from signal generation to data acquisition
1.0 ms to 9.9999 s
DC delay : Time from signal generation to data acquisition
0.0 ms to 9.9999 s
Adjustment delay : Time from DC 0 V signal to data acquisition
3.0 ms to 9.9999 s
Measurement (EXT I/O INDEX signal: Hi)
Switching time
1.5 ms
DC
delay
Switching time
0.5 ms
Switching time depends on the measurement conditions.
The value of the figure is a reference value.
