External Input/Output Connector and Signals
Example output
The decimal point is set to an appropriate position.
12.3456 µF Decimal point: 99.9999 µ
C1
――
D4
――
D3
――
D2
――
D1
――
3 2 1 0 3 2 1 0 3 2 1 0 3 2 1 0
OFF
(High-
order)
Decimal
display
1 2 3 4
BCD
output
OFF OFF OFF ON OFF OFF ON OFF OFF OFF ON ON OFF ON OFF OFF
ON
(Low-
order)
Decimal
display
5 6 Polarity: 0 ERR: 0
BCD
output
OFF ON OFF ON OFF ON ON OFF OFF OFF OFF OFF OFF OFF OFF OFF
-12.345° Decimal point: 99.9999
C1
――
D4
――
D3
――
D2
――
D1
――
3 2 1 0 3 2 1 0 3 2 1 0 3 2 1 0
OFF
(High-
order)
Decimal
display
1 2 3 4
BCD
output
OFF OFF OFF ON OFF OFF ON OFF OFF OFF ON ON OFF ON OFF OFF
ON
(Low-
order)
Decimal
display
5 0 Polarity: 1 ERR: 0
BCD out-
put
OFF ON OFF ON OFF OFF OFF OFF OFF OFF OFF ON OFF OFF OFF OFF
NC (Contact error)
C1
――
D4
――
D3
――
D2
――
D1
――
3 2 1 0 3 2 1 0 3 2 1 0 3 2 1 0
OFF
(High-
order)
Decimal
display
9 9 9 9
BCD
output
ON OFF OFF ON ON OFF OFF ON ON OFF OFF ON ON OFF OFF ON
ON
(Low-
order)
Decimal
display
9 9 Polarity: 0 or 1 ERR: 3
BCD
output
ON OFF OFF ON ON OFF OFF ON OFF OFF OFF OFF
(ON)
OFF OFF ON ON
