83
Setting Application Settings
No. Frequency band Settable range
1 DC (Line frequency 50 Hz) 1 to 2000
1 DC (Line frequency 60 Hz) 1 to 2400
2 4.00 Hz to 10.00 Hz 1 to 4
3 10.01 Hz to 39.99 Hz 1 to 10
4 40.00 Hz to 99.99 Hz 1 to 40
5 100.00 Hz to 300.00 Hz 1 to 50
6 300.01 Hz to 500.00 Hz 1 to 200
7 500.01 Hz to 1.0000 kHz 1 to 300
8 1.0001 kHz to 2.0000 kHz 1 to 600
9 2.0001 kHz to 3.0000 kHz 1 to 1200
10 3.0001 kHz to 5.0000 kHz 1 to 2000
11 5.0001 kHz to 10.000 kHz 1 to 3000
12 10.001 kHz to 20.000 kHz 1 to 1200
13 20.001 kHz to 30.000 kHz 1 to 480
14 30.001 kHz to 50.000 kHz 1 to 800
15 50.001 kHz to 100.00 kHz 1 to 1200
16 100.01 kHz to 140.00 kHz 1 to 2400
17 140.01 kHz to 200.00 kHz 1 to 2400
18 200.01 kHz to 300.00 kHz 1 to 960
19 300.01 kHz to 400.00 kHz 1 to 1600
20 400.01 kHz to 500.00 kHz 1 to 1600
21 500.01 kHz to 700.00 MHz 1 to 2400
22 700.01 kHz to 1.0000 MHz 1 to 2400
23 1.0001 MHz to 1.4000 MHz 1 to 960
24 1.4001 MHz to 2.0000 MHz 1 to 960
25 2.0001 MHz to 3.0000 MHz 1 to 1440
26 3.0001 MHz to 4.0000 MHz 1 to 2400
27 4.0001 MHz to 5.0000 MHz 1 to 2400
28 5.0001 MHz to 6.0000 MHz 1 to 4000
29 6.0001 MHz to 8.0000 MHz 1 to 4000
DC measurement waveform count
performs waveform averaging us-
ing 1/100 of the set line frequency
as one wave.
5 times the number of waves set
with the waveform averaging count
are averaged.
25 times the number of waves set
with the waveform averaging count
are averaged.
125 times the number of waves set
with the waveform averaging count
are averaged.
625 times the number of waves set
with the waveform averaging count
are averaged.
3
Performing Measurements in LCR Mode
