197
Error Indication
<SD Card Error>
Code Error indication Cause Corrective action/more information
SD01 SD card not found.
Insert an SD card.
Data cannot be saved
to the SD memory card
because no SD memory
card has been inserted into
the instrument. Otherwise,
data cannot be loaded
from the SD memory card.
Insert an SD memory card (p. 42).
SD02 Error while attempting to
access the SD card.
You attempted to access a
corrupt le or a corrupt SD
memory card.
Or, the SD memory card
was removed while it was
being accessed.
Copy the data on the SD memory card to
a computer (p. 129) and format the SD
memory card with the instrument (p. 126).
SD03 Unlock the SD card. The SD memory card is in
the locked (write-protected)
state.
Unlock the SD memory card (p. 42).
SD04 SD card is full.
Delete les or reformat.
Data cannot be saved
to the SD memory card
because the card is full.
Execute any of the following.
• Replace the SD memory card with a new
one.
• Copy the data on the SD memory card to
a computer (p. 129), delete unnecessary
data on the card with the instrument
(p. 125), or format the card (p. 126).
SD05 SD card is not formatted
properly.
Format card?
YES: ENTER key
No: ESC key
SD memory card is not
formatted properly.
Format the SD memory card (p. 126).
SD06 SD card not compatible. An unsupported card such
as an SDXC memory card
has been inserted into the
instrument.
Use the instrument’s optional SD memory
card (p. 3).
SD07 This is a read-only le. The SD memory card is in
the locked (write-protected)
state, or the le or folder
attribute is set to “read-
only.”
If the SD memory card is locked, unlock it
(p. 42).
If the le or folder attribute is set to “read-
only,” change the attribute using a computer.
15
Maintenance and Service
