D1-N Series Servo Drive User Manual Advanced Frequency Analysis
10-6 HIWIN MIKROSYSTEM Corp.
MD17UE01-1906
 Filters
There are filters in SMCL tools. Users may use the filters according to their requirements. For how to
set filters, please refer to section 6.6.1.
Figure10.3.2
Setting parameters of filters
Buttons
Display area
