D1-N Series Servo Drive User Manual Wiring
4-2 HIWIN MIKROSYSTEM Corp.
MD17UE01-1906
4.1 System configuration and wiring
The system configuration and wiring of the servo drive are described in this section.
4.1.1 System connection
The names, functions and specifications of terminals on D1-N servo drive are described in the following
figures.
Figure 4.1.1.1
Figure 4.1.1.2
Reactor
Magnetic Contactor
Filter
Circuit Breaker
Regenerative Resistor & DC Link
EtherCAT/Modbus
Communication
Control
Signal
LCD Display
Connect to PC
Safety
Function
Over Temperature
Detection
Digital Encoder
Analog/Serial Encoder
Resolver
Motor Power
24 V
Brake
