D1-N Series Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM Corp. 4-31
MD17UE01-1906
4.12 Accessories of D1-N servo drive
(1) Motor power cable
A. Linear motor
Table 4.12.1
Product Name
Model
Description
Motor Power Cable
LMACSU
Applicable linear motor: LMS, LMSA, LMC-EFE and LMC-EFF
Supports over temperature signal.
D-type connector
220 Vac
LMACSV
Applicable linear motor: LMSA
Supports over temperature signal.
D-type connector
380 Vac
LMACTG
Applicable linear motor: LMSA
Supports over temperature signal.
Round metal connector
220 Vac
LMACTF
Applicable linear motor: LMSA
Supports over temperature signal.
Round metal connector
380 Vac
LMACSM
Applicable linear motor: LMCA, LMCB, LMCC, LMCD, LMCE,
LMC-EFC, LMTA, LMTB, LMTC and LMTD
Supports over temperature signal.
LMACSN
Applicable linear motor: LMCF
Supports over temperature signal.
LMACSS
Applicable linear motor: LMF
Supports over temperature signal.
Round metal connector
Wire diameter: 4.0 mm
2
LMACSZ
Applicable linear motor: LMFA0

, LMFA1

, LMFA2

,
LMFA31, LMFA31L, LMFA32, LMFA32L, LMFA41, LMFA41L,
LMFA42, LMFA42L, LMFA52, LMFA52L and LMFA62
Supports over temperature signal.
Round metal connector
Wire diameter: 1.5 mm
2
LMACTA
Applicable linear motor: LMFA33, LMFA33L, LMFA34, LMFA43,
LMFA43L, LMFA44, LMFA53, LMFA53L, LMFA54, LMFA62L,
LMFA63 and LMFA64
Supports over temperature signal.
Round metal connector
Wire diameter: 2.5 mm
2
LMACTB
Applicable linear motor: LMFA34L, LMFA44L, LMFA54L and
LMFA63L
Supports over temperature signal.
Round metal connector
Wire diameter: 4.0 mm
2
LMACTC
Applicable linear motor: LMFA64L
Supports over temperature signal.
Round metal connector
Wire diameter: 6.0 mm
2
LMACTD
Applicable linear motor: LMTE
Supports over temperature signal.
