D1-N Series Servo Drive User Manual Wiring
4-28 HIWIN MIKROSYSTEM Corp.
MD17UE01-1906
4.9 Motor temperature detection (X9)
D1-N servo drive is able to monitor motor temperature via PTC resistor or NTC resistor.
Figure 4.9.1 Connector: R-MSTB2.5/2-STF (1786831)
Table 4.9.1
Pin Signal
1
T+
2
T-
4.10 Encoder (X10, X11, X12)
D1-N servo drive provides D-Sub high density connectors (15 pins) for encoder feedback.
Figure 4.10.1
Figure 4.10.2
Female
Male
