Hiwin D1-N Series User Manual

D1-N Series Servo Drive User Manual Modbus Communication
HIWIN MIKROSYSTEM Corp. 14-7
MD17UE01-1906
14.3.1 Input register
The data length of readable input register is 32 bits.
Table14.3.1.1
Object Register Address Description Type Unit
1
0x0000
Feedback position
Lower data
INT32 counts
0x0001
Higher data
2
0x0002
Reference position
Lower data
INT32 counts
0x0003
Higher data
4
0x0006
Position error
Lower data
INT32 counts
0x0007
Higher data
10
0x0012
Feedback velocity
Lower data
REAL32 count/s
0x0013
Higher data
11
0x0014
Reference velocity
Lower data
REAL32 count/s
0x0015
Higher data
12
0x0016
Velocity error
Lower data
REAL32 count/s
0x0017
Higher data
30
0x003A
Actual current
Lower data
REAL32 A
amp
0x003B
Higher data
31
0x003C
Command current
Lower data
REAL32 A
amp
0x003D
Higher data
40
0x004E
Analog command
Lower data
REAL32 mV
0x004F
Higher data
41
0x0050
Bus voltage
Lower data
REAL32 V
0x0051
Higher data
51
0x0064
Soft-thermal accumulator
Lower data
REAL32 %
0x0065
Higher data
61
0x0078
Status 5
Lower data
UINT32 -
0x0079
Higher data
81
0x00A0
Status 4
Lower data
UINT32 -
0x00A1
Higher data
90
0x00B2
Status 6
Lower data
UINT32 -
0x00B3
Higher data
91
0x00B4
Status 0
Lower data
UINT32 -
0x00B5
Higher data
2001
0x0FA0
Mode of operation display
Lower data
INT32 -
0x0FA1
Higher data
2002
0x0FA2
Drive error events 1
Lower data
UINT32 -
0x0FA3
Higher data
2003
0x0FA4
Drive error events 2
Lower data
UINT32 -
0x0FA5
Higher data
2004
0x0FA6
Status 1
Lower data
UINT32 -
0x0FA7
Higher data
2005
0x0FA8
Status 2
Lower data
UINT32 -
0x0FA9
Higher data
2006
0x0FAA
Status 3
Lower data
UINT32 -
0x0FAB
Higher data
2008
0x0FAE
Feedback position of second encoder
Lower data
INT32 count
0x0FAF
Higher data
2009
0x0FB0
Hybrid deviation error
Lower data
REAL32 count
0x0FB1
Higher data
