Hiwin D1-N Series User Manual

D1-N Series Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM Corp. 4-5
MD17UE01-1906
4.1.2 Connector specifications
 D1-N-09/18/36
Table 4.1.2.1
Connector Specification Manufacturer
Wire Gauge
Range
Note
Connector for AC
main power cable
European standard 4-pin 7.62 mm
pluggable connector (Female)
PHOENIX
Part number: 1777859
22-12 AWG
Suggested: 12
AWG, 600 V
Connector for
motor power
cable
European standard 4-pin 7.62 mm
pluggable connector (Female)
PHOENIX
Part number: 1778191
22-12 AWG
Suggested: 12
AWG, 600 V
Connector for
regenerative
resistor
European standard 4-pin 5.08 mm
pluggable connector (Male)
PHOENIX
Part number: 1825336
22-14 AWG
Suggested: 14
AWG, 600 V
Connector for
control power
European standard 4-pin 5 mm
pluggable connector (Female)
PHOENIX
Part number: 1786857
22-14 AWG
Suggested: 18
AWG
Connector for
control signals
European standard 40-pin 3.5 mm
pluggable connector (Female)
PHOENIX
Part number: 1790470
24-30 AW G
Connector for
feedback signal
D-Sub 15-pin standard solder
connector (Male)
24-30 AWG
D-Sub 15-pin standard solder
connector (Female)
Connector for
motor over
temperature
signal
European standard 2-pin 5 mm
pluggable connector (Female)
PHOENIX
Part number: 1786831
20-28 AWG
Connector for
safety function
European standard 6-pin 3.5 mm
pluggable connector (Female)
PHOENIX
Part number: 1790302
24-30 AWG
Connector for
mini USB
communication
USB 2.0 type A to
mini-B 5-pin (1.8 M) (Shielding)
HIWIN
Part number:
051700800366
Optional
Note:
Use wiring tools to avoid electric shock when wiring.
