Hiwin D1-N Series User Manual

D1-N Series Servo Drive User Manual Wiring
4-32 HIWIN MIKROSYSTEM Corp.
MD17UE01-1906
 stands for cable length. (Unit: m) The conversion table is as below.
Table 4.12.2

03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
Cable Length 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
B. Torque motor
Table 4.12.3
Product Name Model Description
Motor Power Cable LMACSR
Applicable for torque motor: TMS, TMN and TMX
Over temperature signal is not supported.
 stands for cable length. (Unit: m) The conversion table is as below.
Table 4.12.4

03
04
05
06
07
08
09
10
11
12
13
14
15
16
25
Cable Length
3
4
5
6
7
8
9
10
11
12
13
14
15
16
25
C. AC servo motor
Table 4.12.5
Product Name
Model
Description
Motor Power Cable
HVPS04AAMB
Applicable for 50 W ~ 750 W AC servo motor
Brake signal is not supported.
Highly-bendable
HVPM04BAMB
Applicable for 1 KW ~ 2 KW AC servo motor
Brake signal is not supported.
Straight connector
Highly-bendable
HVPM04CAMB
Applicable for 1 KW ~ 2 KW AC servo motor
Brake signal is not supported.
L-type connector
Highly-bendable
HVPS06AAMB
Applicable for 50 W ~ 750 W AC servo motor
Supports brake signal.
Highly-bendable
HVPM06BAMB
Applicable for 1 KW ~ 2 KW AC servo motor
Supports brake signal.
Straight connector
Highly-bendable
HVPM06CAMB
Applicable for 1 KW ~ 2 KW AC servo motor
Supports brake signal.
L-type connector
Highly-bendable
 stands for cable length. (Unit: m) The conversion table is as below.
Table 4.12.6

03
05
07
10
Cable Length
3
5
7
10
