D1-N Series Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM Corp. 4-33
MD17UE01-1906
(2) Feedback signal cable
A. Linear motor
Table 4.12.7
Product Name
Model
Description
Feedback Signal Cable
LMACFC
D-type connector for motor
For digital reader
Signal of Hall sensor is not supported.
LMACFD
D-type connector for motor
For digital reader
Supports signal of Hall sensor.
LMACFA
D-type connector for motor
For analog reader
Signal of Hall sensor is not supported.
LMACFH
D-type connector for motor
For analog reader
Supports signal of Hall sensor.
LMACFI
Round metal connector for motor
For digital reader
Signal of Hall sensor is not supported.
LMACFB
Round metal connector for motor
For digital reader
Supports signal of Hall sensor.
LMACEAZ
Round metal connector for motor
For analog reader
Signal of Hall sensor is not supported.
LMACFM
Round metal connector for motor
For analog reader
Supports signal of Hall sensor.
Note:
The cables listed in table 4.12.7 are all standard. The connector for encoder is D-type.
 stands for cable length. (Unit: m) The conversion table is as below.
Table 4.12.8

03
04
05
06
07
08
09
10
Cable Length
3
4
5
6
7
8
9
10
