D1-N Series Servo Drive User Manual Wiring
4-34 HIWIN MIKROSYSTEM Corp.
MD17UE01-1906
B. Torque motor
Table 4.12.9
Product Name
Model
Description
Feedback Signal
Cable
LMACFL
For JENA encoder
Applicable torque motor: TMS and TMNE
Supports over temperature signal.
LMACFG
For JENA encoder
Applicable torque motor: TMNEH
Supports over temperature signal and signal of Hall sensor.
LMACFE
For single resolver
Applicable torque motor: TMN
Supports over temperature signal.
LMACFJ
For dual resolver
Applicable torque motor: TMY and TMNA
Supports over temperature signal.
LMACFF For EnDat 2.2 encoder
 stands for cable length. (Unit: m) The conversion table is as below.
Table 4.12.10

02 03 04 05 06 07 08 09 10 11 12 13 14 15
Cable Length
2
3
4
5
6
7
8
9
10
11
12
13
14
15
C. AC servo motor
Table 4.12.11
Product Name
Model
Description
Feedback Signal
Cable
HVE13IADMB
For 13-bit encoder
Applicable for 50 W ~ 750 W AC servo motor
Highly-bendable
HVE13IBDMB
For 13-bit encoder
Applicable for 1 KW ~ 2 KW AC servo motor
Straight connector
Highly-bendable
HVE13ICDMB
For 13-bit encoder
Applicable for 1 KW ~ 2 KW AC servo motor
L-type connector
Highly-bendable
HVE17IADMB
For 17-bit encoder
Applicable for 50 W ~ 750 W AC servo motor
Highly-bendable
HVE17IBDMB
For 17-bit encoder
Applicable for 1 KW ~ 2 KW AC servo motor
Straight connector
Highly-bendable
HVE17ICDMB
For 17-bit encoder
Applicable for 1 KW ~ 2 KW AC servo motor
L-type connector
Highly-bendable
 stands for cable length. (Unit: m) The conversion table is as below.
