D1-N Series Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM Corp. 4-35
MD17UE01-1906
Table 4.12.12

03
05
07
10
Cable Length 3 5 7 10
(3) Control signal cable
Table 4.12.13
Product Name Model Description
Control Signal
Cable
LMACKF
Signal cable for connecting to controller
With bare wires at both ends which can be soldered by users
 stands for cable length. (Unit: m) The conversion table is as below.
Table 4.12.14

02
04
Cable Length
2
4
(4) Communication cable
Table 4.12.15
Product Name
Part Number
Description
USB Communication Cable 051700800366
USB 2.0 type A to mini-B 5-pin
Cable length: 1.8 m
Mini-B connector for servo drive
(5) Connector kit and EMC kit
A. Connector kit
Table 4.12.16
Product Name
Model
Description
Part Number
Qty.
D1-N CK
accessory kit
(For D1-N-09/
18/36)
D1-N CK4
(Part number:
051800200097)
Hose clamp
R-10 mm (Min.) - 16 mm (Max.)
060502600003 1
Connector for AC main power cable
4 pin, pitch 7.62 mm
051500400303 1
Connector for motor power cable
4 pin, pitch 7.62 mm
051500400304 1
Connector for regenerative resistor
4 pin, pitch 5.08 mm
051500400332 1
Connector for control power
4 pin, pitch 5.00 mm
051500400301 1
Connector for control signals:
40 pin, pitch 3.50 mm
051500400316 1
Connector for motor over temperature signal
2 pin, pitch 5.00 mm
051500400306 1
Connector for safety function
6 pin, pitch 3.50 mm
051500400315 2
Connector for feedback signal
D-Sub 15 pin standard solder connector (Male)
051500100045 2
Connector for feedback signal
D-Sub 15 pin standard solder connector (Female)
051500100147 1
D-Sub connector housing
051500600153
2
