D1-N Series Servo Drive User Manual Wiring
4-36 HIWIN MIKROSYSTEM Corp.
MD17UE01-1906
Product Name
Model
Description
Part Number
Qty.
D1-N CK
accessory kit
(For D1-N-90)
D1-N CK5
(Part number:
051800200101)
Hose clamp
R-25 mm (Min.) - 40 mm (Max.)
060502600002 1
Hose clamp
R-10 mm (Min.) - 16 mm (Max.)
060502600003 1
Connector for AC main power cable
4 pin, pitch 10.16 mm
051500400342 1
Connector for motor power cable
4 pin, pitch 10.16 mm
051500400385 1
Connector for regenerative resistor
4 pin, pitch 10.16 mm
051500400342 1
Connector for control power
4 pin, pitch 5.00 mm
051500400301 1
Connector for control signals
40 pin, pitch 3.50 mm
051500400316 1
Connector for motor over temperature signal
2 pin, pitch 5.00 mm
051500400306 1
Connector for safety function
6 pin, pitch 3.50 mm
051500400315 2
Connector for feedback signal
D-Sub 15 pin standard solder connector (Male)
051500100045 2
Connector for feedback signal
D-Sub 15 pin standard solder connector (Female)
051500100147 1
D-Sub connector housing
051500600153
2
B. EMC kit
Table 4.12.17
Product Name
Model
Included Parts
Part No.
Qty.
D1-N EMC accessory
kit (Three-phase)
(For D1-N-09/18/36)
D1-N EMC1
(Part No.:
051800200104)
Three-phase filter B84143A0020R106
(Rated current: 20 A, Leakage current:
3.1 mA)
051800200133 1
Reactor B86305L0016R000 (16 A, 2 mH)
051800200103
1
D1-N EMC accessory
kit
(Single-phase)
(For D1-N-09/18/36)
D1-N EMC2
(Part No.:
051800200107)
Single-phase filter B84113H0000G120
(Rated current: 20 A, Leakage current:
1.73 mA
051800200132 1
Reactor TS10C-16A (2 mH)
051800200106
1
D1-N EMC accessory
kit
(Three-phase)
(For D1-N-90)
D1-N-90 EMC1
(Part No.:
051800200094)
Three-phase filter B84143A0035R166
(Rated current: 35 A, Leakage current:
5.0 mA)
051800200093 1
EMI core KCF-130-B
050300400026
2
D1-N EMC accessory
kit
(Single-phase)
(For D1-N-09/18/36)
D1-N EMC3
(Part No.:
051800200135)
Single-phase filter B84113H0000G120
(Rated current: 20 A, Leakage current:
1.73 mA)
051800200132 1
EMI core KCF-130-B
050300400026
2
D1-N EMC accessory
kit
(Three-phase)
(For D1-N-09/18/36)
D1-N EMC4
(Part No.:
051800200136)
Three-phase filter B84143A0020R106
(Rated current: 20 A, Leakage current:
3.1 mA)
051800200133 1
EMI core KCF-130-B
050300400026
2
Note:
Depending on users’ need, EMI core can be used on main power cable, motor power cable, encoder cable or
pulse control cable to reduce interference.
