Configuration Parameter Definitions
Pen Parameters Set Up Group
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 87
April 2017
Upper Display
Range of Setting or Selection
PEN CHART POSITION FOR ON EVENT — This is the
event marker configuration using digital inputs.
Select the chart position where pen 1 (pen 2) is to mark
(trace) occurrence of an ON event.
ï‚· Prompt only appears if DGTL1 or 2 is selected as pen
1 (pen 2) input.
PEN CHART POSITION FOR OFF EVENT — This is
the event marker configuration using digital inputs.
Select the chart position where pen 1 (pen 2) is to mark
(trace) occurrence of an OFF event.
ï‚· Prompt only appears if DGTL1 or 2 is selected as
pen 1 (pen 2) input.
Repeat this procedure for PEN 2 configuration.
To Next Page
