Configuration Parameter Definitions
Tuning Parameters Set Up Group
102 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Lower Display
Prompt
Upper Display
Range of Setting or Selection
Parameter Definition
PROP BD2
or
GAIN 2
0.1 to 1000%
or
0.1 to 1000
PROPORTIONAL BAND 2 or GAIN 2, RATE 2, and
RESET 2 parameters are the same as previously
described for “Heat” except that they refer to the cool
zone tuning constants on duplex models or the second
set of PID constants, whichever is pertinent.
RATE2MIN
0.08 to 10.00 minutes
0.08 or less = OFF
RSET2MIN
RSET2RPM
0.02 to 50.00
CYC SEC
1 to 120 seconds
CYCLE TIME (HEAT) determines the length of one time
proportional output relay cycle. Defined as "HEAT" cycle
time for Heat/Cool applications.
 Electromechanical relays
CYC2 SEC
1 to 120 seconds
CYCLE TIME 2 (COOL) is the same as above except it
applies to Duplex models as the cycle time in the
"COOL" zone of Heat/Cool applications or for second
set of PID constants.
 Electromechanical relays
