Troubleshooting / Service
Self Diagnostics
210 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release L
February 2017
Lower
Display
Indication
Test Group
Reason for Failure
How to Correct the Problem
EE FAIL
Background
Unable to write to nonvolatile
memory. Any time you change a
parameter and it is not accepted,
you will see EE FAIL.
39. Check the accuracy of the parameter
and re-enter.
40. Try to change something in
configuration.
41. Call Customer Support
1-800-423-9883 USA and Canada.
IN1FAIL
IN2FAIL
Background
Two consecutive failures of input 1
integration (for example, cannot
make analog to digital conversion)
42. Be sure the range and actuation are
configured correctly.
43. Check the input source.
44. Recalibrate. Refer to Section 7 -
Input Calibration.
45. Replace the input card.
46. Call Customer Support
1-800-423-9883 USA and Canada.
BATTERY
Power-up or
Status
Battery test failure.
47. Replace battery.
48. Call Customer Support
1-800-423-9883 USA and Canada
BATT LOW
Background
PV LIMIT
Background
Process Variable is out of range.
±10% of range
49. Be sure pen input configuration is
correct.
50. Check the displayed PV value to see
if it is outside input limits.
51. Call Customer Support
1-800-423-9883 USA and Canada.
RV LIMIT
Background
The result of the formula shown
below is beyond the range of the
remote variable.
RV = INP2 X RATIO + BIAS
1. Make sure the input signal is correct.
2. Make sure the ratio and bias settings
are correct.
3. Go to CONTROL prompt REMOTE
SOURCE and change REMOTE to
1LOCAL.
