Configuration
Configuration Procedure
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 61
April 2017
Step
Operation
Press
Result
5
Change the value or
selection
▲ or ▼
 These keys increment or decrement the value or
selection that appears for the function prompt you have
selected.
 See subsection 3.4 Configuration Tips for instructions
to increase or decrease value quickly.
 Change the value or selection to meet your needs.
 If the display flashes, you are trying to make an
unacceptable entry.
6
Enter the value or selection
FUNC
or
SET
UP
 This key selects another function prompt.
 This key selects another Set Up group.
The value or selection you have made will be entered into
memory after another key is pressed.
7
Exit configuration
LOWR
DISP
This exits configuration mode and returns the recorder to
the same state it was in immediately preceding entry into
the Set Up mode. It stores any changes you have made.
