Honeywell DR4500A User Manual

Configuration
Input Set Up Group
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 63
April 2017
Function Prompt
Lower Display
Function Name
Selections or Range of Setting
Upper Display
Factory
Setting
XMITTER
Transmitter Characterization
B TC S TC
E TC H T TC H
E TC L T TC L
J TC H W TC H
J TC L W TC L
K TC H 100 PT
K TC L 500 PT
NNM TC H 100 RH
NIC TC LINEAR*
R TC SQROOT*
*Set “IN1 HI” and “IN1 LO”
Linear
IN1 HI
Input 1 High Range Value
(linear inputs only)
–999.0 to 9999.
in engineering units
900
IN1 LO
Input 1 Low Range Value
(linear inputs only)
–999.0 to 9999.
in engineering units
-300
CUTOFF 1
Low Flow Cutoff Selection
0 to 100% of input range
0
INPTCOMP
Input Compensation
–999.9 to 9999.
0
FILTER 1
Input 1 Filter
0 to 120 seconds
0
BURNOUT
Burnout Protection
NONE
UP
DOWN
UP
EMISSIV
Emissivity
.01 to 1.00
.01
Repeat this procedure for INPUT 2.
