CONFIGURING MAXPRO NVR

Configuring the System Settings

MAXPRO NVR 5.0 Installation and Configuration Guide 121

3. Click at the bottom of the pane. The Clip Archival is in progress. Please Wait...

message is displayed Figure 6-7.

Figure 6-7 Archive Progress

Note: If the Archival type Disks is not configured then you cannot archive the clips

manually and Failed to archive clip message is displayed.

Once the Manual Archive is success then the selected clips are displayed in Green color

(Figure 6-7) and a Manual archival folder is created automatically for the respective camera. If

it fails then the selected clips are displayed in Pink color.
