4-70
Diagnostic Tests and Utilities
HP Designjet 4000/4020 Printer Series Service Manual
7. Replace Cutter
The purpose of this Service Utility is to move the Carriage to a position
where the Cutter can be replaced easily.
Perform the Replace Cutter utility as follows:
1 In the Service Utilities submenu, scroll to "Replace Cutter" and press Enter.
2 When the following message appears on the front panel, you must select
whether you would like to continue with replacing the Cutter by pressing the
Enter key. Press Back or Cancel to exit the utility.
3 The Carriage will move to the Cutter replacement position and the following
message will be displayed on the Front Panel. After a few seconds the Printer
will begin to shutdown.
4 Before replacing the Cutter, make sure that you switch the Printer OFF from
the rear.
Press Cancel
or the
Back key
Press Enter
to Exit
to replace
the Cutter
P
HO
N
E
S
UP
PO
R
T
