6-33
Print Quality
HP Designjet 4000/4020 Printer Series Service Manual
Image is in One Portion of the Printing Area
If the output that was expected only contains an image in one portion of the
Print Area, then try the following to resolve the problem:
1
Check to see if a too small a page size has been selected in the application.
2 Check to see if the application is set to print the image in only one portion of
the page.
3 If the problem continues, then the cause could be software-printer
incompatibility:
îš„ Check to see if the software is configured correctly for the Printer.
îš„ Try changing the Graphic Language through the Front Panel (Setup
Menu/Printing Defaults Menu/Graphic Language).
îš„ Refer to the Assembly and Setup Poster and the driver documentation.
Image is Unexpectedly Rotated (PostScript Driver)
If the output that was expected contains an image that was unexpectedly
rotated, then try the following to resolve the problem:
1
Check the
rotate
option through the Front Panel (Setup Menu/Printing
Defaults Menu/Paper Options/Rotate) to make sure the rotate option has not
been selected.
2 For non-PostScript files, if Nesting is On, the pages might be automatically
rotated in order to save paper.
3 Check also the following options to see if the rotate option has been
activated by mistake:
îš„ Windows Driver - Finishing tab ? Rotate by 90 degrees.
îš„ Mac OS Driver - Finishing panel ? Rotate by 90 degrees.
îš„ Embedded Web Server - Select Submit Job ? Rotate.
