8-5
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
Installation of New Window
1. Identify the two ends of the Window Hinge
(four in total) - one end is clipped to the
Window and the other to the Top Cover.
2.
Slide the Window Hinges on to the Window.
3. Clip the Window Hinges to the Top Cover.
Since the hinges are very hard to
clip, you will need to forcefully clip
the Window hinges to the Top
Cover.
