Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
Media Deflector
Removal
Switch off the product and remove the power cable.
1. Remove one T-20 screw (Type B) that
secures the Media Deflector that needs to
be replaced.
2. Release the clip securing the Media
Deflector.
3. Remove the Media Deflector (slide
upwards first) from the Printer.
