8-127
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
Front Platen
Removal
Switch off the product and remove the power cable.
1. Open the Window.
2. Remove three T-15 screws and two cross-
head screws that secure the Front Platen.
3. Release the clip on the left hand side of the
Front Platen.
