8-128
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
4. Pull out the left hand side of the Front
Platen.
5. Slide the Front Platen to the Left and then
remove from the Printer.
If a NEW Front Platen is to be installed, make sure that you first remove ALL 3
Media Deflectors (
⇒ Page 8-126 ) from the OLD Front Platen and install them on the
New Front Platen.
1
2
