HP 4000

8-119
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
PrintMech PCA
Removal
Switch off the product and remove the power cable.
1. Remove the Left Connector Cover
⇒ Page
8-19.
2. Remove three T-15 screws (Type A) that
secure the PSU cover.
3. Remove the PSU Cover from the Printer.
4. Disconnect ALL cables from the PrintMech
PCA.
1
2
