8-118
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
17. Release the Power Supply Cable from the
Cable Support Bracket.
18. Remove four T-10 screws (Type I) that
secure the Power Supply Unit.
19. Route the cables through the hole in the
Electronics Module and remove the Power
Supply Unit from the Printer.
To Next Page
