HP 4000

8-18
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
Right Connector Cover
Removal
Switch off the product and remove the power cable.
1. Remove the Rear Door
⇒ Page 8-16 .
2. Remove two T-20 screws (Type B) from the
Right Connector Cover.
3. Remove the Right Connector Cover from
the Printer.
