8-19
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
Left Connector Cover
Removal
Switch off the product and remove the power cable.
1. Remove the Rear Door
⇒
Page 8-16
.
2. Remove two T-20 screws (Type B) from the
Left Connector Cover.
3. Remove the Left Connector Cover from the
Printer.
