5-10
Service Calibrations
HP Designjet 4000/4020 Printer Series Service Manual
2 In the Paper Advance Calibration submenu, scroll to "Print Calibration
Pattern" and press Enter.
3 When the following message appears on the front panel, you must select
whether you would like to continue with the calibration by pressing the
Enter key. Press Back or Cancel to exit the calibration.
4 The Printer will start to calibrate the Analog Encoder and the following
message will be displayed on the Front Panel.
If the Calibration is not done or if the values are out of the limits, a warning
message will appear on the Front Panel. In this case, try the following:
Check that the Printer has the latest Firmware version. If not, update the
Firmware to the latest version.
Retry the Paper Advance Calibration.
If the problem continues, replace the Encoder Strip and Encoder Sensor
⇒ Page 8-72.
Press Cancel
or the
Back key
Press Enter
to Exit
to proceed
