Parts and Diagrams

HP Designjet 4000/4020 Printer Series Service Manual

Printer Support

Reference

Drawing

HP Part Number Quantity Description/Comments

1 Q1271-60454 2 Foot Assembly

2 Q 1271- 60183 2 Le gs A ssembly

3 Q 1271- 60456 1 X-Bra ce Assembly

4 Q1271-60457 1 Bin Assembly (DJ4000)

Q6651-60260 1 Bin Assembly (DJ4020)

- Q1271- 60458 1

Hardware Kit (Includes screws for Legs

Assembly)(DJ4000)

- Q1271-60673 1

Hardware Kit (Includes screws for Legs

Assembly)(DJ4020)

5 Q 1271- 60459 2 Leg Cover
