7-6
Parts and Diagrams
HP Designjet 4000/4020 Printer Series Service Manual
Electronics Module
Electronics Module
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1273-60250 1
Main PCA Formatter (Includes Processor &
Heatsink) (DJ4000)
Q1273-69250 1
Main PCA Formatter (Includes Processor &
Heatsink) - Refurbished (DJ4000)
CM765-60004 1
Main PCA Formatter (Includes Processor &
Heatsink) (DJ4020)
2 Q1273-60298 1 Gamut PCI PCA
Q1273-69298 1 Gamut PCI PCA - Refurbished
3 Q1273-60269 1 Printmech PCA
Q1273-69269 1 Printmech PCA - Refurbished
4 Q1273-60751 1
Hard Disk Drive (Includes Holder and
screws)(DJ4000)
Q1273-69751 1
Hard Disk Drive (Includes Holder and
screws)(DJ4000) - Refurbished
CM767-60003 1
Hard Disk Drive (Includes Holder and
screws)(DJ4020)
5 Q1273-60251 1 Power Supply Unit
Q1273-69251 1 Power Supply Unit - Refurbished
6 Q1273-60267 1 Interconnect PCA
7 Q1273-60249 1 Memory Module 256MB (DJ4000)
CM765-60003 1 Memory Module 512MB (DJ4020)
8 Q1273-60237 1 EIO2PCI Interface
9 Q1273-60238 1 Empty Electronics Module Assembly
10 Q1273-60230 1 Electronics Module Cables Kit
11 Q1273-60272 1 Electronics Module Metal Parts Kit
12 Q5680-60001 1 PCI USB PCA
13 Q5679-60001 1 Gigabit Ethernet PCI Card
