Parts and Diagrams
HP Designjet 4000/4020 Printer Series Service Manual
Right Hand Assemblies
Right Hand Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1273-60255 1 Service Station (Includes Drop Detector)
2 Q1273-60226 1 Aerosol Fan Assembly
3 Q1273-60257 1 Vacuum Fan Assembly
4 Q1273-60236 1 Drop Detector
5 Q1273-60273 1
Service Station Cable (Includes Printhead
Cleaner Door Switch)
6Q1273-600841Aerosol Filter
7Q1273-600861Right Bracket
