7-14
Parts and Diagrams
HP Designjet 4000/4020 Printer Series Service Manual
Left Hand Assemblies
Left Hand Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1273-60244 1 Ink Supply Station (without APS)
2 Q1273-60227 1 Air Pressurization Pump (APS)
3Q1273-602344Cartridge Trays
4Q1273-602291Left Bracket
5 Q1273-60245 1 ISS to Cartridge Cable
6 Q1273-60099 1 Most Left Spittoons
7 Q1273-60227 1 Middle Left Spittoons
