7-18
Parts and Diagrams
HP Designjet 4000/4020 Printer Series Service Manual
Scan-Axis Assemblies
Scan-Axis Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1273-60300 1
Ink Supply Tubes (SRK Tubes w/o Trailing
Cables Serv)
2 Q1273-60228 1 Belt and Tensioner Assembly
3Q1273-600711Scan-Axis Motor
4 Q1273-60239 1 Encoder Strip and Encoder Sensor Kit
5 Q1273-60108 5 Ink Supply Tubes Clips
6Q1273-602662Rear Tube Brackets
7 Q1273-60158 1 Trailing Cable (Data and power)
