7-22
Parts and Diagrams
HP Designjet 4000/4020 Printer Series Service Manual
Paper Path Assemblies
Paper Path Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1Q1273-600411Center Platen
2 Q1273-60060 1 Front Platen
3Q1273-600581Input Roller
4Q1273-601032Input Roller Levers
5 Q1273-60073 1 Media Deflectors Kit
