Parts and Diagrams
HP Designjet 4000/4020 Printer Series Service Manual
Media Entry Assemblies
Media Entry Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1 Q1273-60274 1 Left Roll Module Assembly
2Q1273-602751
Right Roll Module Assembly (Also includes
Right Spindle Lever p/n Q1273-60136)
3 Q1273-60121 1 42" Spindle (does NOT include Blue Hub)
4 C6090-60105 1 Blue Hub
5 C6090-60112 1 3" Spindle Adaptors
6Q1273-601361Right Spindle Lever
